Metal Container House Manufacturer
- One-Stop Solution for Metal Container House
- Custom-Made Layout
- CE-Approved Materials and Equipment
- Offers at affordable rates
- 24/7 Sale and Tech Support
Your Reliable Partner and Manufacturer of Metal Container Office in China
Sunnyda has a full capacity to manufacture a metal container office that easy and quick to install. Our metal container house is made of a superior kind of material that meets international standards.
Our high-quality metal containers house is one of the great places where you can be most comfortable. Using a metal container house is a cheaper way than to build one.
Sunnyda can provide your needs when it comes to container housing. We have a lot of choices for different container houses that will very suited and perfect for your desired applications.
Learn more about the Sunnyda’s product, email us now!
- Gallery
- Data Sheet
| 1 | 20ft Dimension | External Size(mm) | 6058(L)×2438(W)×2791(H) |
| Internal Size(mm) | 5888(L)×2225(W)×2471(H) | ||
| Roof type | Flat roof with slightly slope. Roof drainage system | ||
| Floors allowed | ≤ 3 floors | ||
| 2 | Design specification | Lift span | 20 years |
| Floor live load | 2.5 KN/m² | ||
| Roof live load | 1.0 KN/m² | ||
| Wind load | 1.16 KN/m² | ||
| Seismic proof grade | 8 grade | ||
| 3 | Structure | Column | Galvanized cold roll steel, thk 3.0mm, Q235B |
| Primary roof beam | Galvanized cold roll steel, thk 3.0mm, Q235B | ||
| Secondary roof beam | Cold roll C steel, thk 1.5mm, Q235B | ||
| Primary floor beam | Galvanized cold roll steel, thk 4.0mm, Q235B | ||
| Secondary floor beam | Galvanized cold roll steel, thk 2.0mm, Q235B | ||
| Paint | 40μm epoxy zinc rich primer, 50μm chlorinated rubber topcoat | ||
| Maximum temperature | 500°C | ||
| Color | Any RAL color | ||
| 4 | Roof | Roof boarding | 0.5mm PPGI steel sheet, white grey |
| Insulation | 50mm mineral wool, 60kg/m3, fire rating A, non-inflammable | ||
| Ceiling | 50mm EPS sandwich panel (0.4mm PPGI/50mm EPS/0.4mm PPGI) Or rock wool | ||
| 5 | Floor | Flooring | 2.0mm PVC flooring, |
| Sub-floor | 18mm fiber cement, density≥ 1.3g/cm3 | ||
| Insulation(optional) | 75mm rockwool, 60kg/m3, fire rating A, non-inflammable | ||
| Base plate | 0.5mm PPGI steel sheet, white grey | ||
| 6 | Wall panels | Thickness | 60mm EPS sandwich panel, 0.4mm PPGI/60mm EPS/0.4mm PPGI, PE paint Color white |
| Insulation | 12kg/m3 EPS, | ||
| Option | 60mm rock wool sandwich panel, insulation 100kg/m3 rock wool, A grade fire rating, non-inflammable | ||
| 7 | Door (CE certificate) | Dimension | 2100x900mm |
| Insulation | 40mm rock wool | ||
| Material | Aluminum frame sandwich panel door | ||
| Qty | 1 pc | ||
| 8 | Window with rolling shutter (CE certificate) | Dimension | 800x1100mm |
| Frame material | UPVC | ||
| Glass | Double glazed toughened glass, 5+9A+5mm | ||
| Qty | 1 pc | ||
| 9 | Electricity | Electricity System | Different electrical standards to match with most countries in the world; such as CE, UL, CSA, AS, 220~250V |
| Electricity wire | Input wire 4mm2, stand type A/C wire 4mm2, wall type A/C wire 2.5mm2, switch 1.5mm2 | ||
| Socket | Fit for local standard, 3 pcs | ||
| Switch | 1 pc | ||
| LED light | Double 1200mm LED light, 2 pcs | ||
| 10 | Plumbing System (Option) | Clean Water | Φ20mm PPR |
| Waste water | Φ50mm&Φ110mm UPVC | ||
| 11 | Insulation test result | Floor | Thickness=80mm, U=0.25 W/m² K |
| Roof | Thickness=75mm, U=0.32 W/m² K | ||
| Wall panel | Thickness= 60mm,U=0.59 W/m² K | ||
| Window | Thickness= 5/9/5mm,U=1.4 W/m² K |
Sunnyda Metal Container House
Having Sunnyda metal container house is far less expensive than getting a home in the cheapest place. And you might not even find what you are looking for. But with metal container houses, all you need to do is to look for one and you shall have one.
Sunnyda metal container house is a professional and safe option. Inside our metal container house is sturdy steel construction and turnkey setup is efficiencies. With its appealing spaces and modern designs, our metal container house will look so elegant.
Sunnyda metal container houses are nearly indestructible so you can save time, money, and resources. Safety is our most priority. The very construction and steel composition of metal container house minimize the risks posed by fires.
Our metal container houses are proven to be capable of withstanding extreme heat and surviving fires. Perfectly to use as blast-proof accommodation and fire-proof office. Sunnyda is the most trusted manufacturer who can provide the best kind of metal container house.
We offer the best low-cost metal container house. We design, build and deliver our products nationwide. Those who avail our products can enjoy an affordable architecturally-designed home that is elegant, fully customizable, and sturdy.
Sunnyda manufactured metal container houses of all sizes and types to satisfy all of your needs. Sunnyda has created a solid reputation in the manufacturing industry because of our passionate and highly trained staff.
We made a metal container house fully operational upon delivery. Rest assured that your metal container house arrives in good condition, on-time, like-new, latest, and won’t break your budget.
Sunnyda is ISO qualified and we have complete testing machines and equipment to make sure that you will receive a deserving and satisfying metal container house.
To learn more about our metal container house, get a quote right here, right now!
